2 A horizontal woodren platform 2 M long and 1.5 M wide is supported by four chains from its corners and chairis are attached to a hook 5 M above the center of the platform as shown. Draw projection's of the objects on a suitable scale and determine length of each chain along with its inclination with ground and wall which is parallel to longer edge of the platform.
